HF3-25UA
SATA Revision 3.1
-
Being fully compliant with standard 2.5-inch form factor, providing low power consumption compared to traditional hard drive and hot-swapping.
-
Operating at a maximum operating frequency of 300MHz with 30MHz external crystal.
-
Its capacity could provide a wide range up to 2TB.
-
Reach up to 550MB/s read as well as 530MB/s write high performance based on Toshibas NAND flash (with 256MB/512MB/1024MB/2048MB DDR3 cache enabled and measured by CrystalDiskMark).
Download Files
Product Specifications
| Series Name | HF3-25UA | ||||
|---|---|---|---|---|---|
| Interface | SATA Revision 3.1 | ||||
| Capacity Coverage | 64GB~2TB | ||||
| Capacity | |||||
| SLC | 32GB~256GB | ||||
| MLC | 64GB~2TB | ||||
| 2D pSLC | 32GB~1TB | ||||
| Performance Overview | Seq. R : 550 MB/s ; Seq. W : 530 MB/s | ||||
| Performance | |||||
| SLC | Seq. R : 550 MB/s ; Seq. W : 530 MB/s | ||||
| MLC | Seq. R : 550 MB/s ; Seq. W : 500 MB/s | ||||
| 2D pSLC | Seq. R : 550 MB/s ; Seq. W : 530 MB/s | ||||
| Standard Operating Temperature | 0~70°C | ||||
| Extended Operating Temperature | -40~85°C | ||||
| Dimension LxWxH (mm) | 100.10mm(L) x 69.85mm(W) x 7.00mm(H) | ||||
| Technology | #S.M.A.R.T #PLP ? #conformal coating ? #Write Protect ? #Secure Erase ? | ||||
| Data Sheet |  |
||||
