Enterprise EDSFF E3.S ED / EF Series
PCIe Gen5 x4
-
delivers all the advantages of flash disk technology with PCIe Gen5 x4 interface, including being fully compliant with standard E3.S form factor
-
providing hot-swapping capability when removing/replacing/upgrading flash disks.
-
It offers a wide range of capacities up to 16TB and its performance can reach up to 14,800 MB/s (for sequential read) and 8,700 MB/s (for sequential write) based on TLC NAND flash with the DDR4.
-
the power consumption of E3.S SSD is much lower than traditional hard drives, making it the best embedded solution for new platforms.
Download Files
Product Specifications
| Series Name | Enterprise EDSFF E3.S ED / EF Series | ||||
|---|---|---|---|---|---|
| Interface | PCIe Gen5 x4 | ||||
| Capacity Coverage | OP = 7% : 1920/3840/7680/15360 / OP = 28% : 1600/3200/6400/12800 GB | ||||
| Performance Overview | Seq. R : 14800 MB/s ; Seq. W : 8700 MB/s | ||||
| Performance | |||||
| 3D TLC | Seq. R : 14800 MB/s ; Seq. W : 8700 MB/s | ||||
| Standard Operating Temperature | 0 ~ 70 c | ||||
| Dimension LxWxH (mm) | 112.75(L) x 76(W) x 7.45(H)mm | ||||
| Technology | #PLP ? #Thermal Throttling ? #S.M.A.R.T #AES-XTS ? | ||||
| Data Sheet |  |
||||
