M2P-80DB
NVMe PCIe Gen4 x4
-
The M.2 2280 could provide a wide range capacity up to 8TB.
-
Its performance can reach up to 7,000MB/s read and 2,200MB/s write based on 112Layers 3D TLC NAND flash with the choice of 512MB/1GB/2GB/4GB DDR4.
Download Files
Product Specifications
| Series Name | M2P-80DB | ||||
|---|---|---|---|---|---|
| Interface | NVMe PCIe Gen4 x4 | ||||
| Capacity Coverage | 1TB up to 8TB | ||||
| Capacity | |||||
| 3D TLC | 1TB up to 8TB | ||||
| Performance Overview | Seq. R : 7000 MB/s ; Seq. W : 2200 MB/s | ||||
| Performance | |||||
| 3D TLC | Seq. R : 7000 MB/s ; Seq. W : 2200 MB/s | ||||
| Standard Operating Temperature | 0°C ~ 70°C | ||||
| Extended Operating Temperature | -40°C ~ 85°C | ||||
| Dimension LxWxH (mm) | Dimension of M.2 2280-D2-M: 80mm(L) x 22mm(W) x 3.5mm(H) Dimension of M.2 2280-D2-M (with epoxy glue thickness): 80mm(L) x 22mm(W) x 4.7mm(H) |
||||
| Technology | # #Write Protect ? # # OPAL ? # #Secure Erase ? #FIPS 140-2 ? #Common Criteria ? | ||||
| Data Sheet |  |
||||
